Key Features & Functions
- Self-diagnostic and alarm alert function for easy user maintenance.
- External switch button or remote control for unidirectional or bidirectional passage control.
- Automatic reset function: arm unlocks and rotates 120°/90°, then automatically resets (locks). If no passage occurs within the set time, the system cancels the pass right and closes automatically. Delay adjustable: 2s / 5s / 10s / 60s.
- Anti-rush function: gate arm automatically locks when no open signal is received.
- Anti-tailgating function: rotates 120°/90° per person and automatically locks after each passage.
- Automatic normally-open on power failure to satisfy fire safety regulations.
- Compatible with multiple card reader devices; operates via relay switch signal input.
- Uni/bidirectional passage control for both entry and exit management.
- Optical working principle eliminates input signal delay; prevents multiple persons passing on a single credential.
- External buttons can enable left / right normally-open mode.
- External buttons can enable normally-open without cutting power.
- Remote control and management via management computer (custom order required).
- Control board supports external counter function to record number of persons on-site: entry increments, exit decrements (custom order required).
Technical Specifications
|
Enclosure Dimensions |
1,400(D) × 1,200(W) × 2,200(H) mm |
|
Arm Length |
600 mm |
|
Weight |
Approx. 150 kg / unit |
|
Arm Rotation Angle |
120° |
|
Rotation Direction |
Unidirectional or bidirectional |
|
Power Supply |
AC 220V ± 10%, 50 Hz |
|
Drive Motor |
DC Solenoid 30W / 24V |
|
Input Interface |
Relay switch signal or RS485 level signal |
|
Throughput Speed |
Approx. 40 persons/min (normally open); 25–30 persons/min (normally closed) |
|
Gate Open / Close Time |
1–2 seconds |
|
Enclosure Material |
National Standard SUS304 stainless steel frame |
|
Operating Environment |
Indoor / Outdoor (with rain canopy) |
|
Communication Interface |
RS485 standard (custom order) |
|
Service Life |
5,000,000 cycles |
|
Temperature Range |
–30°C to +80°C |
|
Humidity Range |
5% – 90% RH |
